EcoSmart Fire Flex 104SS.BX2 Wide Bioethanol Fireplace Insert

Description

EcoSmart Fire Flex 104SS.BX2 Bioethanol Fireplace Insert

Create a striking architectural focal point with the EcoSmart Fire Flex 104SS.BX2. Designed to be integrated into cabinetry, feature walls or fireplace settings, this wide single sided bioethanol fireplace delivers a clean, uninterrupted flame view across its 2,650 mm viewing area. With its true zero clearance design and indoor or outdoor application, the Flex 104SS.BX2 gives you the freedom to create a sophisticated fire feature without the need for a chimney, gas connection or traditional fireplace infrastructure.

Features

✨ Wide Single Sided Design

The Flex 104SS.BX2 features an impressive 2,650 mm wide viewing area, allowing the flame to become the main feature of your space. Its all flame configuration keeps the design clean and contemporary, making it ideal for residential living areas, dining rooms, patios and commercial interiors.

The single sided design provides a front facing view of the flame, making it particularly suited to feature walls, built in cabinetry and custom fireplace settings.

🔥 XL1200 Bioethanol Burner

The Flex 104SS.BX2 is designed for the Two Boxes configuration and uses an XL1200 bioethanol burner with a 10 litre fuel capacity.

The burner provides up to 9 to 14 hours of burn time and delivers a thermal output of up to 15,290 BTU/h, 16.13 MJ/h or approximately 4 kW. It can heat an average area of up to 65 m², with a minimum room volume of 115 m³.

Using e NRG bioethanol means there is no need for a gas connection, chimney or traditional flue.

🏡 Indoor or Outdoor Application

The Flex 104SS.BX2 can be used indoors or outdoors when installed in accordance with EcoSmart Fire requirements. It is ideal for creating a warm and inviting atmosphere in living rooms, dining areas, covered patios, outdoor entertaining spaces and commercial environments.

The bioethanol fuel produces a real flame without smoke or ash, helping maintain a clean and contemporary installation.

🧱 True Zero Clearance Construction

Self contained true zero clearance construction provides greater flexibility when designing your fireplace installation. The firebox can be integrated into cabinetry or a feature wall without the conventional clearances associated with many traditional fireplaces.

Always verify the physical product dimensions against the required cut out dimensions before installation to ensure suitable tolerances.

🎨 Clean Architectural Finish

The Flex 104SS.BX2 features a black mild steel surround with a zinc sealed high temperature powder coat. The Grade 304 stainless steel burner is available in stainless steel or black, allowing you to coordinate the fireplace with your overall design.

The included Black Glass Charcoal adds a refined decorative finish around the flame while maintaining the clean appearance of the fireplace.

🛡️ Safety and Certification

The Flex 104SS.BX2 uses a manufacturer approved surround for the BS EN16647 compliant XL1200 burner. EcoSmart Fire fireboxes are manufactured to high standards in accordance with ISO 9001:2008.

The burner complies with applicable standards and requirements including:

• UL 1370 O TL Listed
• EN 16647 BSI Certified
• ACCC Safety Mandate compliant
• Designed for use with e NRG bioethanol

Specifications

📏 Dimensions and Technical Specifications

• Brand: EcoSmart Fire
• Product Type: Single sided bioethanol fireplace insert
• Model: Flex 104SS.BX2
• Configuration: Two Boxes
• Application: Indoor or Outdoor
• Fuel: e NRG Bioethanol
• Burner: XL1200
• Burner Capacity: 10 L
• Burn Time: 9 to 14 hours
• Thermal Output: 15,290 BTU/h / 16.13 MJ/h / 4 kW
• Fuel Consumption: 0.87 L/h
• Average Heating Area: 65 m²
• Minimum Room Size: 115 m³
• Model Dimensions: W 2,851 mm x D 365 mm x H 807 mm
• Viewing Area: W 2,651 mm x D 340 mm x H 502 mm
• Weight: 146.2 kg
• Model Material: Mild Steel with zinc sealed high temperature powder coat
• Burner Material: Grade 304 Stainless Steel
• Model Colour: Black
• Burner Colour: Stainless Steel or Black
• Configuration: All Flame
• Certification: UL 1370, EN 16647 BSI, ACCC Safety Mandate
• Quality Standard: ISO 9001:2008

Included

📦 What’s Included

The Flex 104SS.BX2 includes:

• XL Baffles
• Jerry Can 5 L
• Fire Lighter
• Lighting Rod
• Bottle Adaptor
• Black Glass Charcoal
• Integrated fire screen

The XL Baffles help regulate and stabilise the flame while supporting efficient fuel use. The included lighting accessories make filling, lighting and adjusting the burner easier and more controlled.

🌿 Optional Accessories

Copper Log Set

Add a more traditional decorative touch with the optional Copper Log Set. Made from stainless steel, this decorative log set provides an attractive finishing detail around the flame.

📦 Packaging Specifications

• Shipping Weight: 192 kg
• Packaging Dimensions: L 2,937 mm x W 536 mm x H 1,068 mm
• Cubic Volume: 1.68 m³
• Packaging Type: Crate with skid

Delivery

🚚 Delivery Information

We work with selected freight companies to help provide a fast and reliable delivery service.

Standard delivery provides ground delivery to the easiest access point on your property. It does not include inside delivery, packaging removal or assembly.

Please ensure there is suitable access for delivery of your order.

Bioethanol Fuel Delivery

e NRG Bioethanol may be shipped separately from your EcoSmart Fire order and may arrive on a different day. A separate tracking number will be provided for your e NRG Bioethanol order.

Warranty

🤝 Warranty and Support

EcoSmart Fire products are manufactured to high standards and designed for long term performance. Please follow the manufacturer's installation, operation and maintenance requirements to ensure safe and reliable use.

For integrated installations, professional installation is recommended. Always check the product dimensions and installation requirements before work begins.

Safety

⚠️ Safety Information

The Flex 104SS.BX2 is a bioethanol fireplace with separate indoor and outdoor operating requirements.

Only use the recommended e NRG bioethanol fuel and operate the fireplace according to the manufacturer's instructions. Never refill a burner while it is lit or still hot. Allow the burner to cool completely before refuelling.

Ensure the installation meets the required dimensions, room volume and safety clearances before use. Keep combustible materials away from the flame and never leave a burning fireplace unattended.

FAQs

❓ Frequently Asked Questions

Can the Flex 104SS.BX2 be installed indoors?

Yes. The Flex 104SS.BX2 is designed for indoor or outdoor application, subject to the applicable installation requirements and room volume requirements.

How long does the XL1200 burner burn?

The XL1200 burner provides approximately 9 to 14 hours of burn time depending on operating conditions and fuel use.

How much space can the Flex 104SS.BX2 heat?

The XL1200 configuration can heat an average area of up to 65 m². A minimum room volume of 115 m³ is required for this configuration.

Does the Flex 104SS.BX2 need a chimney?

No traditional chimney or flue is required. The fireplace uses e NRG bioethanol and is designed as a self contained fireplace system. Installation must still follow all applicable manufacturer requirements.

Can the Flex 104SS.BX2 be built into cabinetry?

Yes. Its true zero clearance construction allows the fireplace to be integrated into suitable cabinetry, feature walls and custom fireplace settings. Installation dimensions must be checked before construction begins.

Is the Flex 104SS.BX2 suitable for outdoor use?

Yes. It can be used outdoors when installed in an appropriate environment and according to EcoSmart Fire's outdoor installation requirements.

Downloads

Model Specifications

Clearance & Installation - Flex Series

Installation & Operation - Ethanol Burners
