EcoSmart Fire Flex 104SS.BXR Wide Bioethanol Fireplace with Dual XL900

Description

🔥 EcoSmart Fire Flex 104SS.BXR Wide Bioethanol Fireplace Insert

Create a spectacular architectural feature with the EcoSmart Fire Flex 104SS.BXR, an extra wide single sided bioethanol fireplace insert designed to combine contemporary styling with impressive flame coverage and flexible installation. With a generous 2,650 mm viewing area and dual XL900 burners, this fireplace brings real flame and warmth to large residential and commercial spaces while integrating neatly into cabinetry, feature walls and custom fireplace settings.

Features

✨ Extra Wide Single Sided Design

The Flex 104SS.BXR is designed for a single room application with one open side, allowing the flame to be viewed clearly from the front. Its expansive 2,650 mm viewing area creates a dramatic focal point, while the clean black finish complements a wide range of architectural styles.

The Box Right configuration provides a balanced flame feature while allowing the fireplace to be incorporated into a custom design with the box positioned on the right side.

🔥 Dual XL900 Bioethanol Burners

The Flex 104SS.BXR uses two XL900 bioethanol burners with a combined fuel capacity of 18 litres. The dual burner configuration delivers up to 30,000 BTU/h, 32 MJ/h or 8.8 kW of thermal output.

With an approximate burn time of 8 to 13 hours, it provides long lasting flame and warmth for larger living and entertaining spaces.

XL Baffles are included to help regulate and stabilise the flames while supporting efficient fuel use.

🏡 Indoor or Outdoor Application

The Flex 104SS.BXR is suitable for indoor or outdoor applications when installed according to the manufacturer's requirements and applicable local regulations.

Its extra wide format makes it well suited to large dining rooms, open plan living spaces, outdoor entertaining areas and suitable commercial environments.

Powered by clean burning e NRG bioethanol, the fireplace does not require a traditional chimney or gas utility connection, providing greater flexibility for suitable architectural installations.

🧱 True Zero Clearance Construction

The self contained true zero clearance construction provides flexibility for integrating the Flex 104SS.BXR into suitable feature walls, cabinetry and fireplace settings.

The surround is constructed from mild steel with a zinc sealed high temperature powder coat finish, while the XL900 burners are made from Grade 304 stainless steel.

This design gives builders, architects, interior designers and homeowners greater freedom when creating a custom fireplace feature.

Always verify the physical fireplace dimensions against the required cut out dimensions before installation begins to ensure suitable tolerances.

🌟 High Heat Output for Larger Spaces

The dual XL900 configuration provides substantial warmth across larger areas while maintaining an impressive flame display.

The Flex 104SS.BXR can heat an average area of approximately 120 m² and requires a minimum room size of 220 m³ for this configuration.

Key performance figures include:

• 18 litre combined fuel capacity
• 8 to 13 hour burn time
• 30,000 BTU/h thermal output
• 32 MJ/h thermal output
• 8.8 kW thermal output
• Fuel consumption of approximately 1.6 L/h
• Heating coverage of approximately 120 m²
• Minimum room size of 220 m³

Performance figures are indicative only and may vary depending on the model, installation environment and composition of the e NRG bioethanol used.

🎨 Decorative Finishing Options

The Flex 104SS.BXR includes Black Glass Charcoal, providing a sleek contemporary finish around the flame. The tempered glass decorative media is designed to withstand temperatures of up to 700°C.

For a warmer and more traditional appearance, the optional Copper Log Set adds an elegant finishing touch to the fireplace.

🛡️ Safety and Certification

The Flex 104SS.BXR features a manufacturer approved surround for the BS EN16647 compliant XL900 burner configuration.

EcoSmart Fire manufactures its fireboxes to high standards in accordance with ISO 9001:2008. The bioethanol burners also comply with recognised standards and safety requirements across key markets.

Certifications and compliance include:

• UL 1370 listed
• EN 16647 BSI Certified
• ACCC Safety Mandate compliant
• ISO 9001:2008 manufacturing standards

The integrated fire screen and included XL Baffles provide additional support for controlled operation.

Specifications

📏 Dimensions and Technical Specifications

• Brand: EcoSmart Fire
• Product Type: Single sided bioethanol fireplace insert
• Model: Flex 104SS.BXR
• Application: Indoor or Outdoor
• Configuration: Box Right
• Burner: XL900 x2
• Fuel Type: e NRG Bioethanol
• Combined Burner Capacity: 18 L
• Burn Time: 8 to 13 hours
• Thermal Output: 30,000 BTU/h / 32 MJ/h / 8.8 kW
• Fuel Consumption: 1.6 L/h
• Heating Coverage: 120 m²
• Minimum Room Size: 220 m³
• Model Width: 2,850 mm
• Model Height: 807 mm
• Model Depth: 365 mm
• Viewing Area Width: 2,650 mm
• Viewing Area Height: 502 mm
• Viewing Area Depth: 340 mm
• Weight: 146.2 kg
• Model Material: Mild Steel with zinc sealed high temperature powder coating
• Burner Material: Grade 304 Stainless Steel
• Model Colour: Black
• Burner Colours: Stainless Steel or Black
• Certification: UL 1370, EN 16647 BSI, ACCC Safety Mandate
• Manufacturing Standard: ISO 9001:2008

📦 Packaging Specifications

• Shipping Weight: 189 kg
• Packaging Length: 2,937 mm
• Packaging Width: 536 mm
• Packaging Height: 1,068 mm
• Packaging Volume: 1.68 m³
• Packaging Type: Crate with skid

Included

📦 What’s Included

The EcoSmart Fire Flex 104SS.BXR includes:

• XL Baffles
• Jerry Can 5 L
• Fire Lighter
• Lighting Rod
• Bottle Adaptor
• Black Glass Charcoal
• Integrated fire screen

These accessories provide the essentials for fuelling, ignition, flame adjustment and decorative finishing.

🌿 Optional Accessories

• Copper Log Set

The stainless steel Copper Log Set adds a refined decorative element and can create a more traditional fireplace appearance.

Delivery

🚚 Delivery Information

We work with selected freight companies to help provide a fast and reliable delivery service.

Standard delivery provides ground delivery to the easiest access point on your property. It does not include inside delivery, packaging removal or assembly.

Please ensure there is suitable access for delivery of your order, particularly as the Flex 104SS.BXR has a shipping weight of approximately 189 kg and is supplied in a large crate with skid.

Bioethanol Fuel Delivery

e NRG Bioethanol may be shipped separately from your EcoSmart Fire order and may arrive on a different day. A separate tracking number will be provided for your e NRG Bioethanol order.

Warranty

🤝 Warranty and Support

EcoSmart Fire products are designed and manufactured with quality, durability and safety in mind. For installation, fuel and operating guidance, always follow the manufacturer's instructions and applicable local requirements.

For custom installations, professional advice should be obtained to ensure the fireplace, surrounding materials and installation environment are suitable for the intended application.

Safety

⚠️ Safety Information

Bioethanol fireplaces must always be installed and operated in accordance with the manufacturer's instructions and applicable local regulations.

The Flex 104SS.BXR is a bioethanol fireplace with separate indoor and outdoor operating requirements. Ensure suitable clearances, appropriate surrounding materials and the required installation conditions are provided for the intended application.

Never refuel a burner while it is operating or still hot. Allow the burners to cool completely before refuelling and use only the recommended e NRG bioethanol fuel.

Physical model dimensions should be verified against cut out dimensions BEFORE installation begins to confirm tolerances align.

FAQs

❓ Frequently Asked Questions

Can the Flex 104SS.BXR be installed indoors?

Yes. The Flex 104SS.BXR is suitable for indoor or outdoor applications when installed according to the manufacturer's requirements and applicable local regulations.

How many burners does the Flex 104SS.BXR have?

The Box Right configuration uses two XL900 bioethanol burners with a combined fuel capacity of 18 litres.

How long does the Flex 104SS.BXR burn?

The dual XL900 configuration provides an approximate burn time of 8 to 13 hours. Actual burn time can vary depending on installation conditions and fuel composition.

How much space can the Flex 104SS.BXR heat?

The XL900 x2 configuration is rated to heat an average area of approximately 120 m² and requires a minimum room size of 220 m³.

Does the Flex 104SS.BXR require a chimney?

No traditional chimney is required. The self contained bioethanol design provides greater flexibility for suitable architectural fireplace installations.

What fuel does the Flex 104SS.BXR use?

The fireplace is designed for use with e NRG bioethanol fuel. Always use the recommended fuel and follow the manufacturer's fuelling instructions.

What is included with the Flex 104SS.BXR?

The fireplace includes XL Baffles, a 5 litre Jerry Can, Fire Lighter, Lighting Rod, Bottle Adaptor, Black Glass Charcoal and an integrated fire screen.

Can the Flex 104SS.BXR be integrated into cabinetry?

Yes. The true zero clearance construction provides flexibility for integrating the fireplace into suitable cabinetry, feature walls and fireplace settings, subject to the manufacturer's installation requirements.

Downloads

Model Specifications

Clearance & Installation - Flex Series

Installation & Operation - Ethanol Burners
