EcoSmart Fire Flex 50SS Wide Single Sided Bioethanol Fireplace Insert

Description

🔥 EcoSmart Fire Flex 50SS Single Sided Bioethanol Fireplace Insert

Create an impressive centrepiece with the EcoSmart Fire Flex 50SS, a wide single sided bioethanol fireplace insert designed to make the flame the star of your space. With a generous 1,270 mm viewing area, clean architectural lines and a powerful XL900 burner, the Flex 50SS combines contemporary styling with the inviting character of a real fire.

Designed for integration into suitable cabinetry, feature walls and fireplace settings, this substantial fireplace insert brings warmth and atmosphere to residential, commercial and alfresco environments without the need for a traditional chimney or gas connection.

Features

✨ Expansive All Flame Design

The Flex 50SS features a single open side that provides a clear front facing view of the flame.

Its impressive 1,270 mm wide viewing area is dedicated to the fire, creating a dramatic horizontal feature that can become the focal point of a large living room, dining area, outdoor room or commercial space.

The sleek black surround provides a sophisticated backdrop while allowing the dancing flame to take centre stage.

🔥 Powerful XL900 Bioethanol Burner

The Flex 50SS is fitted with the XL900 burner, providing a generous 9 litre fuel capacity and an approximate burn time of 8 to 13 hours.

The XL900 produces up to 15,000 BTU/h of thermal output and can heat an average area of up to 60 m², depending on the installation environment and operating conditions.

XL Baffles are included to help regulate and stabilise the flame while supporting efficient fuel use.

🏡 Indoor and Outdoor Applications

The Flex 50SS is suitable for indoor and outdoor applications, giving you flexibility when creating a substantial built in fire feature.

Its wide format is particularly well suited to feature walls, cabinetry and fireplace settings where a generous horizontal flame creates a strong architectural statement.

Always ensure the installation meets the manufacturer's requirements and verify the physical fireplace dimensions against the required cut out dimensions before installation.

🛠️ True Zero Clearance Design

The self contained zero clearance construction provides flexibility for suitable architectural installations.

The Flex 50SS does not require a traditional chimney or gas utility connection, helping create a streamlined fireplace design while simplifying integration into an appropriate setting.

Professional installation is recommended for built in applications, and all manufacturer installation requirements must be followed.

🌱 Clean Burning Bioethanol

Powered by e NR G bioethanol, the Flex 50SS creates a real flame without the need for traditional firewood.

Bioethanol provides a convenient alternative to conventional fireplaces, allowing you to enjoy warmth and ambience without the smoke, soot and ash associated with wood burning.

🖤 Sleek Contemporary Finish

The Flex 50SS features a black mild steel surround with a zinc sealed high temperature powder coated finish.

The XL900 burner is available in stainless steel or black, allowing you to coordinate the burner with your chosen fireplace design.

The understated finish keeps attention focused on the flame while complementing contemporary interiors and outdoor spaces.

🪵 Decorative Design Options

The Flex 50SS includes Black Glass Charcoal as decorative media, adding a refined finishing touch around the flame.

An optional Copper Log Set is also available for customers who want to introduce a more traditional fireplace character. The stainless steel log set provides an eye catching decorative element while complementing the contemporary firebox design.

🛡️ Safety and Certification

The Flex 50SS features a manufacturer approved surround for the BS EN16647 compliant XL900 burner.

The burner is O T L listed to UL 1370, BSI certified to EN16647 and compliant with the ACCC Safety Mandate for bioethanol burners.

The firebox is manufactured to high standards in accordance with ISO 9001:2008.

Always use approved e NR G bioethanol and follow the manufacturer's instructions for installation, filling, lighting, operation and extinguishing.

Specifications

📏 Dimensions & Technical Specifications

• Brand: EcoSmart Fire
• Product Type: Single sided bioethanol fireplace insert
• Model: Flex 50SS
• Configuration: All Flame
• Application: Indoor and outdoor
• Fuel Type: e NR G bioethanol
• Burner: XL900
• Burner Capacity: 9 L
• Burn Time: 8 to 13 hours
• Thermal Output: 15,000 BTU/h / 15.83 MJ/h / approximately 4 kW
• Fuel Consumption: 0.8 L/h on maximum setting
• Heating Capacity: Up to 60 m²
• Minimum Room Size: 110 m³
• Model Width: 1,470 mm
• Model Height: 807 mm
• Model Depth: 365 mm
• Viewing Area Width: 1,270 mm
• Viewing Area Height: 502 mm
• Viewing Area Depth: 340 mm
• Weight: 71.4 kg
• Surround Material: Mild steel with zinc sealed high temperature powder coating
• Burner Material: Grade 304 stainless steel
• Model Colour: Black
• Burner Colours: Stainless Steel and Black
• Certification: UL 1370, EN16647 BSI Certified and ACCC Safety Mandate compliant
• Shipping Weight: 88 kg
• Packaging Dimensions: 1557 mm L x 536 mm W x 1068 mm H
• Packaging Type: Crate with skid
• Packaging Volume: 0.89 m³

Performance figures are indicative only and may vary depending on the model, installation environment and composition of the e NR G bioethanol used.

The Flex 50SS specifications also list an alternative XL500 configuration for certain box left or right applications. The figures above relate to the All Flame XL900 configuration supplied for this model.

Physical model dimensions should always be checked against the required cut out dimensions before installation begins.

Included

📦 What’s Included

Your EcoSmart Fire Flex 50SS includes:

• XL Baffles
• Jerry Can 5 L
• Fire Lighter
• Lighting Rod
• Bottle Adaptor
• Black Glass Charcoal
• Integrated fire screen

The XL Baffles help regulate and stabilise the flame, while the Black Glass Charcoal provides a stylish decorative finish around the fireplace.

🧰 Optional Accessories

Copper Log Set

The optional Copper Log Set is made from stainless steel and provides a decorative finishing touch for the fireplace. Its warm copper appearance can add a traditional character to the contemporary Flex design.

Delivery

🚚 Delivery Information

We work with selected freight companies to help provide a fast and reliable delivery service.

Standard delivery provides ground delivery to the easiest access point on your property. It does not include inside delivery, packaging removal or assembly.

Please ensure there is suitable access for delivery of your order. Due to the packaged weight of 88 kg and the substantial crate dimensions, suitable access and handling space should be available.

Bioethanol Fuel Delivery

e NR G Bioethanol may be shipped separately from your EcoSmart Fire order and may arrive on a different day. A separate tracking number will be provided for your e NR G Bioethanol order.

Warranty

🤝 Warranty & Support

EcoSmart Fire products are designed using quality materials and components for reliable, long lasting performance. The Flex 50SS is supported by the manufacturer's applicable warranty terms.

Before installation, carefully check the fireplace dimensions against the required cut out dimensions. Always follow the manufacturer's installation, operating and maintenance instructions.

Safety

⚠️ Safety Information

Always read and follow the manufacturer's installation, safety and operating instructions before using the Flex 50SS.

Professional installation is recommended for built in applications. Always verify the physical model dimensions against the required cut out dimensions before installation.

Only use approved e NR G bioethanol. Never refill the burner while it is burning or hot. Allow the burner to cool completely before refuelling.

Keep combustible materials away from the fireplace and maintain all required clearances. Never modify or move the fireplace while the burner is lit or hot.

Wood burning and gas products are designed for use outdoors in a well ventilated space. The Flex 50SS is a bioethanol fireplace and has separate indoor and outdoor operating requirements. Always ensure the installation and ventilation requirements specified by the manufacturer are followed.

FAQs

❓ Frequently Asked Questions

Is the Flex 50SS a single sided fireplace?

Yes. The Flex 50SS has one open side, allowing the flame to be viewed directly from the front.

How wide is the viewing area?

The viewing area measures 1,270 mm wide, 502 mm high and 340 mm deep, providing a generous view of the flame.

How long does the XL900 burner burn?

The 9 litre XL900 burner provides an approximate burn time of 8 to 13 hours, depending on operating conditions.

How much space can the Flex 50SS heat?

The XL900 burner can heat an average area of up to 60 m², depending on the installation environment and other conditions.

Can the Flex 50SS be used outdoors?

Yes. The Flex 50SS is suitable for indoor and outdoor applications, subject to the manufacturer's installation and operating requirements.

Does the Flex 50SS require a chimney?

No. The bioethanol fireplace does not require a traditional chimney or gas connection.

What fuel does the Flex 50SS use?

The Flex 50SS is designed to use e NR G bioethanol. Only the manufacturer's recommended fuel should be used.

Can I add decorative logs?

Yes. The optional Copper Log Set is available as a decorative accessory for the Flex 50SS.
