EcoSmart Fire Flex 68SS.BX2 Wide Bioethanol Fireplace with XL500 Burner

Description

🔥 EcoSmart Fire Flex 68SS.BX2 Wide Bioethanol Fireplace Insert

Create a dramatic fireplace feature with the EcoSmart Fire Flex 68SS.BX2, a wide single sided bioethanol fireplace insert designed for integrated cabinetry, feature walls and fireplace settings. With an impressive 1,731 mm viewing area and two box configuration, this fireplace combines contemporary styling with the natural appeal of a real flame. It is an excellent choice for creating a striking focal point in residential, commercial and suitable outdoor living spaces.

Features

✨ Expansive Single Sided Design

The Flex 68SS.BX2 features a single open side, allowing the flame to be viewed from the front across an exceptionally wide viewing area.

Its generous proportions make it ideal for larger living rooms, dining areas, feature walls, hospitality spaces and outdoor living environments. The sleek black surround provides a refined architectural finish that works beautifully with contemporary interiors.

The all flame design keeps attention focused on the fire, creating a clean and uninterrupted visual display.

🔥 XL500 Bioethanol Burner Configuration

The Flex 68SS.BX2 is designed around the XL500 burner configuration, with a 5 litre fuel capacity and an approximate burn time of 10 to 13 hours.

The burner provides up to 12 MJ/h, 11,430 BTU/h or approximately 3.4 kW of thermal output and can heat an average area of up to 40 m², depending on the installation environment and operating conditions.

XL Baffles are included to help regulate and stabilise the flame while supporting efficient fuel use.

🏡 Indoor or Outdoor Application

The Flex 68SS.BX2 is designed for indoor or outdoor applications, providing flexibility when planning your fireplace installation.

Create a sophisticated centrepiece in a living room or dining area, integrate it into a feature wall, or incorporate it into a suitable outdoor living space.

Powered by clean burning e NRG bioethanol, the fireplace produces a real flame without wood, ash or the need for a traditional chimney.

🧱 True Zero Clearance Construction

The self contained true zero clearance construction provides greater flexibility for builders, architects, interior designers and homeowners.

The Flex 68SS.BX2 can be integrated into suitable cabinetry, feature walls and fireplace settings, subject to the manufacturer's installation requirements.

Physical model dimensions should always be verified against the required cut out dimensions before installation begins to ensure the correct tolerances are maintained.

🌟 Efficient Heat Without a Traditional Chimney

The Flex fireplace uses a closed combustion system designed to retain heat within the room rather than losing warmth through traditional venting.

With no chimney or utility connection required, the Flex 68SS.BX2 provides a streamlined way to introduce a large fireplace feature while maintaining a clean and contemporary appearance.

🎨 Decorative Finishing Options

Black Glass Charcoal is included with the Flex 68SS.BX2, adding a sleek decorative element around the flame.

The optional Copper Log Set can be added to create a warmer and more traditional fireplace appearance. Made from stainless steel, it provides an attractive decorative finish while complementing the contemporary design of the Flex range.

🛡️ Safety and Certification

The Flex 68SS.BX2 includes a manufacturer approved surround designed for the BS EN16647 compliant XL500 burner.

The fireplace complies with applicable standards across the USA, Europe, UK and Australia. The bioethanol burner is:

• O T L listed to UL 1370
• EN 16647 BSI Certified
• ACCC Safety Mandate compliant

The fireboxes are manufactured to high standards in accordance with ISO 9001:2008.

Specifications

📏 Dimensions and Technical Specifications

• Brand: EcoSmart Fire
• Product Type: Single sided bioethanol fireplace insert
• Model: Flex 68SS.BX2
• Configuration: Two Boxes
• Application: Indoor or Outdoor
• Burner: XL500
• Fuel Type: e NRG Bioethanol
• Burner Capacity: 5 L
• Burn Time: 10 to 13 hours
• Thermal Output: 12 MJ/h / 11,430 BTU/h / 3.4 kW
• Fuel Consumption: 0.5 L/h
• Heating Coverage: Up to 40 m²
• Minimum Room Size: 80 m³
• Model Width: 1,931 mm
• Model Height: 807 mm
• Model Depth: 365 mm
• Viewing Area Width: 1,731 mm
• Viewing Area Height: 502 mm
• Viewing Area Depth: 340 mm
• Construction Weight: 93.9 kg
• Model Material: Mild steel with zinc sealed, high temperature powder coat
• Burner Material: Grade 304 stainless steel
• Model Colour: Black
• Burner Colours: Stainless Steel or Black
• Certification: UL 1370, EN 16647 BSI, ACCC compliant
• Packaging Type: Crate with skid
• Shipping Weight: 132 kg
• Packaging Dimensions: 2,477 x 536 x 1,067 mm
• Packaging Volume: 1.42 m³

Performance figures are indicative only and may vary depending on the model, installation environment and composition of the e NRG bioethanol sourced in each country.

Included

📦 What’s Included

The EcoSmart Fire Flex 68SS.BX2 includes:

• XL Baffles
• Jerry Can 5L
• Fire Lighter
• Lighting Rod
• Bottle Adaptor
• Black Glass Charcoal
• Integrated fire screen
• Manufacturer approved surround for the XL500 burner

The Black Glass Charcoal is made from high quality tempered glass and is designed to withstand temperatures of up to 700°C.

🌿 Optional Accessories

Copper Log Set

The optional Copper Log Set is made from stainless steel and adds a decorative finishing touch to the fireplace. It provides a warmer, more traditional fireplace appearance while complementing the clean architectural lines of the Flex 68SS.BX2.

Delivery

🚚 Delivery Information

We work with selected freight companies to help provide a fast and reliable delivery service.

Standard delivery provides ground delivery to the easiest access point on your property. It does not include inside delivery, packaging removal or assembly.

Please ensure there is suitable access for delivery of your order, particularly due to the substantial dimensions and 132 kg shipping weight of the Flex 68SS.BX2.

Bioethanol Fuel Delivery

e NRG Bioethanol may be shipped separately from your EcoSmart Fire order and may arrive on a different day. A separate tracking number will be provided for your e NRG Bioethanol order.

Warranty

🤝 Warranty and Support

EcoSmart Fire products are manufactured to high quality standards and designed for reliable performance. For installation, operation and maintenance, always follow the manufacturer's instructions and use approved fuel and accessories.

Professional installation is recommended to ensure the fireplace is correctly integrated into its intended setting and complies with applicable safety requirements.

Safety

⚠️ Safety Information

Always read and follow the manufacturer's installation and operating instructions before using the fireplace.

Only use approved e NRG bioethanol fuel and follow the manufacturer's instructions for filling, lighting and extinguishing the burner.

Never refuel while the burner is lit or still hot. Allow the burner to cool completely before refuelling.

The fireplace must be installed in accordance with applicable building, fire and safety regulations.

Always verify the physical model dimensions against the required cut out dimensions before installation begins.

Wood burning and gas products are designed for use outdoors in a well ventilated space. The Flex 68SS.BX2 is a bioethanol fireplace and has separate indoor and outdoor operating requirements.

FAQs

❓ Frequently Asked Questions

Can the Flex 68SS.BX2 be installed indoors?

Yes. The Flex 68SS.BX2 is designed for indoor or outdoor applications. Indoor installation must follow the manufacturer's installation requirements and applicable local regulations.

What burner does the Flex 68SS.BX2 use?

The Flex 68SS.BX2 uses the XL500 bioethanol burner configuration with a 5 litre fuel capacity.

How long does the XL500 burner burn?

The XL500 provides an approximate burn time of 10 to 13 hours, depending on operating conditions and fuel consumption.

How much space can the Flex 68SS.BX2 heat?

The XL500 configuration can heat an average area of up to 40 m². Actual performance can vary depending on room size, installation environment and other conditions.

Does the Flex 68SS.BX2 need a chimney?

No. The bioethanol fireplace does not require a traditional chimney or flue, making it suitable for integrated fireplace designs.

Can the Flex 68SS.BX2 be integrated into cabinetry?

Yes. The Flex 68SS.BX2 is designed for integration within suitable cabinetry, feature walls and fireplace settings. Installation must follow the manufacturer's construction, clearance and safety requirements.

What does BX2 mean?

The BX2 configuration refers to the two box configuration of the Flex 68SS.BX2. The supplied efficiency information specifies the XL500 burner configuration for this model.

What is the viewing area?

The Flex 68SS.BX2 has a generous viewing area measuring approximately 1,731 mm wide by 502 mm high, providing a wide view of the flame.

What decorative media is included?

Black Glass Charcoal is included. The optional Copper Log Set is available separately for an alternative decorative finish.

Does the Flex 68SS.BX2 come with a fire screen?

Yes. An integrated fire screen is included and sits flush behind the frame.

Downloads

Model Specifications

Clearance & Installation - Flex Series

Installation & Operation - Ethanol Burners
