EcoSmart Fire Orbit 360 Degree Freestanding Bioethanol Fireplace

Description

🔥 EcoSmart Fire Orbit Bioethanol Fireplace

Make a bold statement with the EcoSmart Fire Orbit, a futuristic freestanding indoor fireplace designed to bring a striking 360 degree flame into your living space. Raised above the floor and surrounded by tall toughened glass, Orbit creates an impressive focal point that can be enjoyed from different angles. Its sculptural black finish, clean lines and dancing bioethanol flame make it a stylish choice for modern homes, entertaining areas, hospitality spaces and contemporary interiors.

Features

✨ Sleek Design for Modern Interiors

Orbit combines a slim raised profile with a strong architectural presence. Its black powder coated stainless steel stand gives the fireplace a sophisticated modern appearance, while the tall glass surrounds provide an unobstructed view of the flame.

The elevated design helps Orbit visually define a room without making the space feel enclosed. It can be positioned as a central feature, placed alongside furniture or used to create a defined zone within an open plan interior.

The rotating design also gives you flexibility when arranging your space, allowing the fireplace to become a focal point from different viewpoints.

🔥 360 Degree Flame Experience

At the centre of Orbit is the EcoSmart Fire AB3 bioethanol burner, offering a captivating flame that can be appreciated from multiple angles. The 2.5 litre burner provides approximately 8 to 11 hours of burn time, depending on operating conditions and fuel consumption.

Powered by e NRG bioethanol, Orbit provides a real flame without the need for wood, ash or a traditional chimney. This makes it an appealing option for customers who want the atmosphere of a fireplace with a simpler fuel system and less everyday mess.

With a thermal output of approximately 5,800 BTU per hour, Orbit can help take the chill off your indoor space while creating a warm and inviting atmosphere.

👀 Glass Surround for Flame Visibility

The tall toughened glass panels create a beautiful viewing experience while helping protect the flame from the surrounding space. The transparent design means the fire remains visually prominent without blocking your view across the room.

This makes Orbit particularly effective in open plan living areas, lounges, reception spaces and entertaining areas where the fireplace can be appreciated from several positions.

An optional D60 Fire Screen is also available for Orbit, providing additional protection and helping shield the flame from internal draughts.

🏡 Flexible Freestanding Design

Orbit does not require hardwired utilities, giving you greater flexibility when planning your interior. Its freestanding format allows it to be positioned where it can have the greatest visual impact, whether that is in the centre of a room, beside seating or as part of a carefully designed interior feature.

The raised design is especially suited to contemporary spaces where a fireplace needs to do more than provide warmth. Orbit acts as both a functional fire and a distinctive architectural feature, helping create a welcoming atmosphere for relaxing evenings and entertaining guests.

🌱 Clean Burning Bioethanol Fuel

Orbit is fuelled by e NRG bioethanol, a clean burning liquid fuel designed for EcoSmart Fire bioethanol burners. Unlike a traditional wood burning fireplace, there is no wood to store and no ash left behind after use.

The bioethanol burner also allows you to enjoy a real flame without the traditional chimney and flue arrangement associated with many conventional fireplaces. Always follow the manufacturer's requirements for room size, ventilation, positioning and safe operation.

🛡️ Safety and Certification

The AB3 burner is designed and tested to meet recognised international safety standards. It is BSI Certified to EN 16647, O TL listed to UL 1370 in the USA and compliant with the ACCC Safety Mandate for Australia.

Always read and follow the manufacturer's installation, operation and safety instructions before using Orbit. Keep combustible materials away from the fireplace and ensure the required room size, ventilation and clearances are maintained.

Specifications

📏 Dimensions & Technical Specifications

• Brand: EcoSmart Fire
• Product Type: Freestanding bioethanol fireplace
• Model: Orbit
• Application: Indoor
• Burner: AB3
• Fuel Type: e NRG bioethanol
• Burner Capacity: 2.5 litres
• Burn Time: 8 to 11 hours
• Thermal Output: 5,800 BTU per hour
• Thermal Output: Approximately 6.12 MJ per hour
• Fuel Consumption: 0.31 litres per hour on maximum
• Heating Capacity: Approximately 20 m²
• Minimum Room Size: 40 m³
• Width: 550 mm
• Height: 986 mm
• Depth: 550 mm
• Weight: Approximately 54.3 kg
• Materials: Black powder coated stainless steel and toughened glass
• Burner Material: Grade 304 stainless steel with black ceramic coating
• Model Colour: Black
• Burner Colour: Black
• Certification: EN 16647 BSI Certified
• Certification: O TL listed to UL 1370
• Australian Compliance: ACCC Safety Mandate compliant

Performance figures are indicative and may vary depending on the model, installation environment and composition of the e NRG bioethanol used.

Included

📦 What’s Included

• EcoSmart Fire Orbit fireplace
• AB3 bioethanol burner
• Jerry Can Spout Extension
• Jerry Can 5L
• Fire Lighter
• Lighting Rod
• Bottle Adaptor
• Toughened glass fire screen
• Manufacturer approved surround for the AB3 burner

🛠️ Optional Accessories

The Orbit can be enhanced with additional accessories designed to provide greater protection and flexibility.

• D60 Fire Screen for additional protection and draught resistance

Warranty

🤝 Warranty & Support

EcoSmart Fire Orbit is crafted from durable materials and designed for long lasting performance. The combination of powder coated stainless steel, toughened glass and the purpose designed AB3 bioethanol burner creates a fireplace made for both visual impact and everyday enjoyment.

For safe and reliable operation, always use the recommended e NRG bioethanol fuel and follow the manufacturer's instructions for filling, lighting, extinguishing and maintenance.

Safety

⚠️ Safety Information

Always operate the EcoSmart Fire Orbit in accordance with the manufacturer's safety instructions. Keep combustible materials away from the fireplace and never leave a burning flame unattended.

Use only the recommended e NRG bioethanol fuel. Allow the burner to cool completely before refuelling and never add fuel to a hot or burning burner.

Orbit is an indoor fireplace and must be used in an appropriately ventilated room that meets the manufacturer's minimum room requirements. Maintain suitable clearances around the fireplace and follow all positioning and operating instructions.

Wood burning and gas products are designed for use outdoors in a well ventilated space. This warning does not apply to Orbit, which is an indoor bioethanol fireplace.

FAQs

❓ Frequently Asked Questions

Is the EcoSmart Fire Orbit suitable for outdoor use?

No. Orbit is designed for indoor use only and should not be installed or operated outdoors.

How long does the Orbit AB3 burner burn?

The 2.5 litre AB3 burner provides approximately 8 to 11 hours of burn time, depending on operating conditions and fuel consumption.

What fuel does Orbit use?

Orbit uses e NRG bioethanol, a clean burning liquid fuel designed for EcoSmart Fire bioethanol burners.

Does Orbit require a chimney or flue?

The AB3 bioethanol burner does not require a traditional chimney or flue. However, the fireplace must be operated according to the manufacturer's requirements, including appropriate ventilation and room size.

Can Orbit be positioned in different parts of a room?

Yes. Orbit is a freestanding fireplace that does not require hardwired utilities, giving you greater flexibility when positioning it within a suitable indoor space.

Can the Orbit fireplace rotate?

Yes. The rotating design allows the fireplace to be positioned and enjoyed from different viewpoints within the room.

Does Orbit produce smoke or ash?

The clean burning bioethanol flame does not produce wood ash or soot, helping to keep maintenance simple compared with a traditional wood burning fireplace.

Is a fire screen available for Orbit?

Yes. The optional D60 Fire Screen is designed for EcoSmart Fire Orbit and can help protect the flame from internal draughts.
