EcoSmart Frame 1200SS Built In Bioethanol Fireplace with Wide Flame

Description

EcoSmart Fire Frame 1200SS Built In Bioethanol Fireplace 🔥

Create an impressive centrepiece for large living spaces with the EcoSmart Fire Frame 1200SS. Designed for homeowners who love to entertain, this wide single sided bioethanol fireplace delivers a spectacular flame display while maintaining a clean and sophisticated architectural appearance.

With a generous 1266 mm viewing area and powerful XL900 burner, the Frame 1200SS brings warmth and atmosphere to spacious living rooms, open plan interiors, hospitality settings and covered outdoor entertaining areas. Its self contained bioethanol technology also offers installation flexibility without the need for a gas connection, electricity or conventional chimney.

Features

🏡 Designed to Make an Impression

The Frame 1200SS is made for spaces where the fireplace needs to be more than a source of warmth. Its generous width creates a strong horizontal feature that naturally draws attention and provides an inviting focal point for entertaining.

The single sided design gives you a clear front view of the flame, making it particularly effective when incorporated into a feature wall or architectural fireplace installation.

The sleek black surround works with a wide range of interior styles, from contemporary open plan living spaces to sophisticated hospitality and entertaining areas.

🔥 Powerful XL900 Bioethanol Burner

At the heart of the Frame 1200SS is the XL900 bioethanol burner. With a 9 litre fuel capacity and an indicative burn time of 8 to 13 hours, it provides an extended flame experience for dinner parties, relaxed evenings and special occasions.

The XL900 produces approximately 15,000 BTU/h of thermal output and is designed to heat an average area of around 60 m². Maximum fuel consumption is approximately 0.8 litres per hour.

The included XL Baffles help regulate and stabilise the flame while supporting fuel efficiency, helping create a consistent and visually appealing flame across the wide fireplace.

🌿 No Gas, Chimney or Electricity Required

The Frame 1200SS uses a self contained bioethanol burner, eliminating the need for a mains gas connection or electrical utility connection.

The fireplace is designed to operate without a conventional chimney or flue when installed according to the manufacturer's requirements. This can provide greater flexibility when planning a new fireplace feature or updating an existing interior.

Compatible e NRG bioethanol provides the fuel for the flame without the need to store or burn traditional firewood.

Always follow the manufacturer's requirements for ventilation, room volume, clearances and installation.

✨ Flexible Built In Installation

The Frame 1200SS is designed for suitable built in installations and can be incorporated into wood or metal stud structures, subject to the manufacturer's requirements.

Its flexible design can also be useful for renovation and retrofit projects where major structural changes need to be minimised. The surrounding wall finish can be customised and updated over time, helping the fireplace remain relevant as your interior evolves.

🎨 Complete Design Freedom

The generous proportions of the Frame 1200SS provide plenty of scope for creative interior design.

Integrate the fireplace into a marble feature wall, timber surround, concrete finish or bespoke millwork to create a completely personalised look.

Its clean black surround allows the flame to remain the visual focus while the surrounding materials add texture, colour and personality to the space.

💎 Premium Materials

The Frame 1200SS combines robust construction with sophisticated styling.

The surround is made from mild steel with zinc sealing and a high temperature powder coated finish. The XL900 burner is constructed from Grade 304 stainless steel and is available with an optional black ceramic coating.

A toughened low iron glass fire screen provides a clear view of the flame while complementing the streamlined design.

Safety

🛡️ Safety and Global Compliance

The Frame 1200SS is designed to comply with applicable standards in the USA, Europe, UK and Australia. The XL900 bioethanol burner is O TL listed to UL 1370, EN 16647 and BSI certified, with ACCC Safety Mandate compliance according to the manufacturer's supplied information.

Important safety information:

• Use compatible bioethanol fuel only.

• Never refuel while the burner is lit or hot.

• Allow the burner to cool completely before refuelling.

• Keep children, pets and combustible materials away from the flame.

• Maintain the required ventilation, room volume and installation clearances.

• Check physical model dimensions against the required cut out dimensions before installation.

• Use the supplied lighting and refuelling accessories according to the manufacturer's instructions.

• Wood burning and gas products are designed for outdoor use in a well ventilated space. This model uses bioethanol and must be installed according to its specific indoor or outdoor requirements.

• Always consult the latest EcoSmart Fire installation and operating instructions before use.

Specifications

📐 Dimensions and Technical Specifications

• Brand: EcoSmart Fire

• Product Name: Frame 1200SS

• Product Type: Built in bioethanol fireplace

• Design: Single sided

• Application: Indoor or outdoor

• Model Colour: Black

• Burner Colour: Stainless steel, with black option available

• Burner Configuration: XL900

• Surround Material: Mild steel with zinc sealing and high temperature powder coating

• Burner Material: Grade 304 stainless steel

• Fire Screen: Toughened low iron glass

• Overall Width: 1416 mm (55.7 in)

• Overall Height: 598 mm (23.5 in)

• Overall Depth: 363 mm (14.3 in)

• Viewing Area Width: 1266 mm (49.8 in)

• Viewing Area Height: 398 mm (15.7 in)

• Product Weight: 57.9 kg (127.6 lb)

• Bioethanol Capacity: 9 litres (2.4 US gallons)

• Bioethanol Burn Time: Approximately 8 to 13 hours

• Fuel Consumption: Approximately 0.8 litres per hour at maximum

• Thermal Output: Approximately 15,000 BTU/h, 15.83 MJ/h, 4 kW

• Average Heating Area: Approximately 60 m² (646 ft²)

• Minimum Room Volume: 110 m³ (3,885 ft³)

• Shipping Weight: 54 kg (119 lb)

• Packaging Length: 1495 mm (58.9 in)

• Packaging Width: 467 mm (18.4 in)

• Packaging Height: 805 mm (31.7 in)

• Packaging Volume: 0.56 m³

• Packaging Type: Carton with skid

Performance figures are indicative only and may vary depending on the installation environment, model and composition of the e NRG bioethanol used.

Included

📦 What's Included

The Frame 1200SS includes:

• Frame 1200SS fireplace

• XL900 bioethanol burner

• XL Baffles

• 5 litre Jerry Can

• Refillable fire lighter

• Lighting rod

• Bottle adaptor

The supplied accessories are designed to support fuel storage, refuelling, ignition and flame adjustment when used according to the manufacturer's instructions.

Delivery

🚚 Delivery Information

Standard delivery provides ground delivery to the easiest accessible point on your property. It does not include inside delivery, packaging removal or assembly.

Due to its substantial size and weight, please check doorways, access routes and the intended installation area before ordering. Ensure the delivery location provides suitable access for the packaged fireplace.

e NRG bioethanol may be shipped separately from the EcoSmart Fire order and may arrive on a different day. A separate tracking number will be provided for the fuel shipment.

Warranty

🔧 Warranty and Support

The EcoSmart Fire Frame 1200SS is designed for homeowners who want a substantial fireplace feature with an impressive linear flame. Its generous proportions, extended burn time and flexible built in design make it an excellent choice for large living spaces and entertaining areas.

For assistance with installation requirements, wall materials, fuel selection or choosing the right EcoSmart Fire model, contact the Sal’s Place team before ordering. Always verify physical dimensions, clearances, access requirements and installation conditions before work begins.

FAQs

❓ Frequently Asked Questions

Does the Frame 1200SS require a chimney?

No traditional chimney is required. The self contained XL900 bioethanol burner is designed to operate without a conventional chimney or flue when installed according to the manufacturer's requirements.

Does the Frame 1200SS need gas or electricity?

No. The fireplace uses bioethanol and does not require a mains gas or electrical connection.

How long does the Frame 1200SS burn?

The 9 litre XL900 burner provides an indicative burn time of approximately 8 to 13 hours. Actual burn time depends on operating conditions and fuel composition.

How much space can it heat?

The XL900 burner is designed to heat an average area of approximately 60 m². Actual heating performance depends on the room, insulation, installation and environmental conditions.

Can the Frame 1200SS be used outdoors?

Yes. The model is listed for indoor and outdoor applications. Outdoor installation must meet the manufacturer's requirements for location, protection, ventilation and safe operation.

What are the XL Baffles used for?

The XL Baffles help regulate and stabilise the flame while supporting fuel efficiency of the XL900 burner.

Can I customise the wall around the fireplace?

Yes. The Frame series can be integrated with suitable materials such as marble, timber, concrete and custom millwork. Always follow the manufacturer's installation clearances and material requirements.

Is the Frame 1200SS suitable for large entertaining spaces?

Yes. With a 1266 mm wide viewing area and XL900 burner, the Frame 1200SS is designed to create a strong visual centrepiece in spacious living rooms, open plan areas and entertaining spaces.

Is the Frame 1200SS suitable for apartments?

The Frame series has been designed with urban living in mind, but suitability depends on the specific property, local regulations and installation requirements. Always confirm suitability before installation.

Downloads

Frame 1200SS Fireplace - Model Specifications

Clearances & Installation Manual - Frame Fireplaces

Installation & Operation - Ethanol Burners
