EcoSmart Frame 600SS Built In Bioethanol Fireplace for Modern Homes

Description

EcoSmart Fire Frame 600SS Built In Bioethanol Fireplace 🔥

Bring the warmth and atmosphere of a real flame into compact living spaces with the EcoSmart Fire Frame 600SS. Designed for intimate rooms, accent walls and apartment interiors, this single sided built in bioethanol fireplace combines sophisticated styling with a space conscious design.

With its clean lines, black surround, stainless steel burner and generous 596 mm viewing area, the Frame 600SS creates an elegant focal point without taking over the room. Its self contained bioethanol burner eliminates the need for gas lines, electricity, a chimney or traditional flue, giving you greater freedom when planning a new fireplace or updating an existing wall.

Features

🏡 Sophisticated Fireplace Design for Smaller Spaces

The Frame 600SS has been designed specifically for spaces where traditional fireplaces may not be practical. Its compact proportions make it well suited to cosy living rooms, bedrooms, apartments, feature walls and renovation projects.

The single sided design provides a clear view of the flame from the front, while the minimalist black surround allows the fireplace to complement a wide range of interior styles.

Whether surrounded by marble, timber, concrete or custom millwork, the Frame 600SS can be incorporated into your chosen aesthetic for a personalised fireplace feature.

🔥 Clean Burning Bioethanol Flame

The Frame 600SS uses the BK5 bioethanol burner, offering a 5 litre fuel capacity and an indicative burn time of 7 to 11 hours.

The burner produces approximately 13,000 BTU/h of thermal output and can heat an average area of around 35 m². Fuel consumption is approximately 0.64 litres per hour at maximum.

Using compatible e NRG bioethanol means there is no need for firewood, gas or electrical connections. The result is an inviting flame that provides warmth and ambience without the ash and soot associated with traditional wood burning fireplaces.

✨ Flexible Built In Installation

One of the key advantages of the Frame 600SS is its flexible installation design. Its self contained construction allows the fireplace to be incorporated into suitable wood or metal stud walls, subject to the manufacturer's installation requirements.

The design is also well suited to renovation projects. Wall finishes can be updated over time without necessarily requiring the entire fireplace design to be changed, making the Frame 600SS a practical option for evolving interiors.

Its space conscious design requires minimal wall cavity preparation, making it particularly appealing for retrofit projects where major structural changes need to be avoided.

🏢 Ideal for Apartments and Urban Homes

Traditional fireplaces can be difficult to install in apartments and modern properties due to requirements for chimneys, flues, gas connections and venting.

The Frame 600SS offers a different approach. Its bioethanol burner is self contained and does not require a gas connection, electrical connection or conventional chimney, giving homeowners greater flexibility when creating a fireplace feature in a suitable apartment or urban living space.

Always follow the manufacturer's installation requirements, including room volume, clearances and ventilation requirements.

💎 Premium Materials

The Frame 600SS combines durable materials with contemporary design.

The surround is constructed from mild steel with zinc sealing and a high temperature powder coated finish. The fireplace features a Grade 304 stainless steel burner and toughened low iron glass for a clear view of the flame.

The burner is supplied in stainless steel, while the model features a sophisticated black finish that works beautifully with both contemporary and traditional interiors.

Safety

🛡️ Safety and Global Compliance

The Frame 600SS is designed to meet applicable standards across the USA, Europe, UK and Australia. The BK5 bioethanol burner is O TL listed to UL 1370, EN 16647 and BSI certified, with compliance with the Australian ACCC Safety Mandate according to the manufacturer.

Important safety information:

• Use compatible bioethanol fuel only.

• Never refuel while the burner is lit or hot.

• Allow the burner to cool completely before refuelling.

• Keep children, pets and combustible materials away from the flame.

• Maintain the required ventilation, room volume and clearances.

• Check physical model dimensions against the required cut out dimensions before installation.

• Use the supplied lighting and refuelling accessories according to the manufacturer's instructions.

• Wood burning and gas products are designed for outdoor use in a well ventilated space. This model uses bioethanol and must be installed according to its specific indoor or outdoor requirements.

• Always consult the latest EcoSmart Fire installation and operating instructions before use.

Specifications

📐 Dimensions and Technical Specifications

• Brand: EcoSmart Fire

• Product Name: Frame 600SS

• Product Type: Built in bioethanol fireplace

• Design: Single sided

• Application: Indoor or outdoor

• Model Colour: Black

• Burner Colour: Stainless steel

• Burner Configuration: BK5

• Surround Material: Mild steel with zinc sealing and high temperature powder coating

• Burner Material: Grade 304 stainless steel

• Fire Screen: Toughened low iron glass

• Overall Width: 746 mm (29.4 in)

• Overall Height: 798 mm (31.4 in)

• Overall Depth: 403 mm (15.9 in)

• Viewing Area Width: 596 mm (23.5 in)

• Viewing Area Height: 598 mm (23.5 in)

• Product Weight: Approximately 29 kg as listed in construction data

• Bioethanol Capacity: 5 litres (1.3 US gallons)

• Bioethanol Burn Time: Approximately 7 to 11 hours

• Fuel Consumption: Approximately 0.64 litres per hour at maximum

• Thermal Output: Approximately 13,000 BTU/h, 13.72 MJ/h, 4 kW

• Average Heating Area: Approximately 35 m² (377 ft²)

• Minimum Room Volume: 70 m³ (2,472 ft³)

• Shipping Weight: 34 kg (74.96 lb)

• Packaging Length: 825 mm (32.5 in)

• Packaging Width: 507 mm (20 in)

• Packaging Height: 875 mm (34.4 in)

• Packaging Volume: 0.37 m³

• Packaging Type: Carton

Performance figures are indicative only and may vary depending on installation environment, model and fuel composition.

Included

📦 What's Included

The Frame 600SS includes:

• Frame 600SS fireplace

• BK5 bioethanol burner

• 5 litre Jerry Can

• Refillable fire lighter

• Lighting rod

• Bottle adaptor

The supplied accessories are designed to support safe fuel storage, refuelling, ignition and flame adjustment when used according to the manufacturer's instructions.

Delivery

🚚 Delivery Information

Standard delivery provides ground delivery to the easiest accessible point on your property. It does not include inside delivery, packaging removal or assembly.

Please check access routes, doorways and the intended installation area before ordering to ensure the fireplace can be safely delivered to the property.

e NRG bioethanol may be shipped separately from the EcoSmart Fire order and may arrive on a different day. A separate tracking number will be provided for the fuel shipment.

Warranty

🔧 Warranty and Support

The EcoSmart Fire Frame 600SS offers a stylish solution for bringing real flame ambience into compact homes, apartments and carefully designed feature walls. Its single sided design, flexible installation options and self contained bioethanol burner make it an attractive alternative to conventional fireplaces.

For assistance with installation requirements, wall materials, fuel selection or choosing the right EcoSmart Fire model, contact the Sal’s Place team before ordering. Always verify dimensions, clearances and installation requirements before work begins.

FAQs

❓ Frequently Asked Questions

Does the Frame 600SS require a chimney?

No traditional chimney is required. The self contained BK5 bioethanol burner is designed to operate without a conventional chimney or flue when installed according to the manufacturer's requirements.

Does it need gas or electricity?

No. The Frame 600SS uses bioethanol and does not require a mains gas or electrical connection.

How long does the Frame 600SS burn?

The 5 litre BK5 burner has an indicative burn time of approximately 7 to 11 hours. Actual burn time depends on operating conditions and fuel composition.

How much space can it heat?

The BK5 burner is designed to heat an average area of approximately 35 m². Actual heating performance depends on the room and installation environment.

Can the Frame 600SS be installed in an apartment?

It is designed with urban and apartment living in mind and can be installed in suitable properties, subject to local regulations and the manufacturer's installation requirements.

Can I customise the wall around the fireplace?

Yes. The Frame series is designed to integrate with a variety of finishing materials, including marble, timber, concrete and custom millwork. Always follow the specified installation clearances and material requirements.

Is the Frame 600SS suitable for renovations?

Yes. Its space conscious design and flexible built in installation make it particularly suitable for retrofit and renovation projects where major structural modifications should be minimised.

Downloads

Frame 600SS Fireplace - Model Specifications

Clearances & Installation Manual - Frame Fireplaces

Installation & Operation - Ethanol Burners
