Foco Free 1200 Manual Bioethanol Fireplace

Description

Foco Free 1200 Manual Bioethanol Fireplace

Bring a striking panoramic flame feature into your home with the Foco Free 1200. Designed for custom interiors and DIY fireplace projects, this four sided bioethanol fireplace offers a generous 120 cm width and an open design that lets you enjoy the flames from multiple angles. Whether incorporated into a dividing wall, a bespoke furniture feature or an island style installation, it creates a contemporary focal point without the need for a chimney or flue.

🔥 A Panoramic Fireplace for Custom Interiors

The Foco Free 1200 gives you the flexibility to create a fireplace that suits your space. Its minimalist black frame and four sided flame view work beautifully in modern living rooms, open plan spaces and individually designed interiors.

Measuring 120 cm wide and 40 cm deep, the fireplace is designed to be integrated into a custom structure. The included safety glass panels help shield the flames from draughts while maintaining a clear view of the fire.

Features

✨ Key Features

• Four sided panoramic flame view

• Generous 120 cm width for a statement fireplace feature

• Sleek black steel frame with a 4 mm thickness

• Manual burner with adjustable flame height

• No chimney or flue required

• Four tempered glass panels and eight glass holders included

• Designed for built in installation and DIY projects

• Two year warranty

🔥 Manual Bioethanol Burner

This listing is for the manual burner configuration. The burner offers an approximately 80 cm flame length, with a stated heat output range of 3.3 to 6.5 kW. Its 5 litre fuel capacity provides a burn time of up to 6 hours, depending on the flame setting and operating conditions.

The flame is adjusted manually, giving you control over its appearance without electrical power. Automatic burner functions, remote control and app control are not included with this manual configuration.

🖤 Durable Construction and Modern Finish

The Foco Free 1200 features a black powder coated steel frame with a stated steel thickness of 4 mm. Its understated design complements a wide range of interior styles while keeping the flame as the main visual feature.

Four tempered glass panels are supplied with the fireplace, along with eight glass holders. The glass helps reduce the effect of draughts around the flames. Always follow the manufacturer's installation guidance when deciding how to position and fit the glass.

Specifications

📐 Technical Specifications

• Brand: Foco Fires

• Model: Foco Free 1200

• Fireplace type: Four sided bioethanol fireplace insert

• Width: 120 cm

• Depth: 40 cm

• Packaging depth: 44.5 cm

• Packaged weight: 19.8 kg

• Frame material: Steel

• Finish: Black powder coated

• Steel thickness: 4 mm

• Burner type: Manual bioethanol burner

• Flame length: Approximately 80 cm

• Heat output: 3.3 to 6.5 kW

• Fuel capacity: 5 litres

• Fuel consumption: Listed as 0.87 litres per hour

• Burn time: Up to 6 hours

• Minimum recommended room volume: 90 m³

• Chimney or flue: Not required

• Glass: Included

• Power supply: Not required for the manual burner

• Warranty: 2 years

Please note that the general product data lists a maximum heat output of 6.2 kW, while the manual burner table lists 3.3 to 6.5 kW. Confirm the final specification with the supplier if the exact heat output is important for your installation.

Included

📦 What's Included?

• Foco Free 1200 fireplace frame, supplied in two parts

• One manual bioethanol burner

• Four tempered glass panels, approximately 10 cm high

• Eight glass holders

Automatic burners, remote controls, mobile app controls, Smart Home modules and optional accessories are not included.

Safety

🛠️ Installation and Safety

The Foco Free 1200 is designed for integration into a custom built fireplace feature. Although it is intended to support DIY projects, the surrounding structure must be suitable for use with a real flame appliance. Use appropriate fire resistant materials and insulation where required, and follow the manufacturer's installation and clearance instructions.

Bioethanol fireplaces produce real flames and require adequate ventilation. Keep furniture, curtains and other combustible materials at a safe distance. Never refill the burner while it is hot or burning, and allow it to cool completely before refuelling. Use only the recommended bioethanol fuel and never leave a lit fireplace unattended.

FAQs

❓ Frequently Asked Questions

Does the Foco Free 1200 need a chimney?

No. A chimney or flue is not required, but the room must have adequate ventilation and meet the manufacturer's minimum room size and installation requirements.

Is this listing for a manual or automatic burner?

This listing is for the manual burner configuration. Automatic burners and their remote, app or Smart Home controls are not included.

Can I adjust the flame?

Yes. The manual burner's flame can be adjusted by hand according to the manufacturer's instructions.

How long does the burner run?

The stated burn time is up to 6 hours. Actual running time depends on the flame setting and operating conditions.

Can I install it in a custom wall or furniture feature?

It is designed for custom built installations. The surrounding structure must be suitable for a real flame fireplace, with the required clearances, ventilation and fire resistant materials.

Is the glass included?

Yes. Four tempered glass panels and eight glass holders are included.
