Foco One 800 Built In Bioethanol Fireplace with Adjustable Flames

Description

Foco One 800 Built In Bioethanol Fireplace with Adjustable Flames

Create a striking focal point in your home with the Foco One 800 built in bioethanol fireplace. Designed for contemporary interiors, this elegant single sided fireplace brings the beauty of real flames into your living room, dining area or open plan space without the need for a traditional chimney. Its clean lines and black finish create a sophisticated look, while the adjustable flames let you tailor the atmosphere to suit everything from quiet evenings at home to entertaining guests.

Features

🔥 Modern Design and Quality Materials

The Foco One 800 features a minimalist design that sits neatly within a wall, leaving the flames as the main attraction. Its 80 cm wide frame is made from 4 mm thick steel with a black powder coated finish, offering a durable construction and a refined appearance that complements modern homes.

The single sided design means the fire is viewed from the front, making it ideal for a feature wall or a built in fireplace installation. A tempered glass panel is included to help shield the flames from draughts, supporting a steadier and more attractive flame display.

✨ Adjustable Flames and Flexible Burner Options

Choose a manual or automatic bioethanol burner to suit your preferred level of convenience. The manual burner offers straightforward operation without an electrical connection, while compatible automatic burners provide more advanced controls.

Depending on the burner selected, you can enjoy features such as remote control, mobile app operation and multiple flame settings. Selected Planika automatic burners also support smart home integration when fitted with the appropriate optional equipment.

Bioethanol fuel produces a real flame without the need for a conventional flue or chimney. This gives you greater flexibility when planning a stylish fireplace installation in a suitable indoor space.

Burner performance, flame length, fuel capacity, heat output and operating time vary according to the model selected. Check the specifications for your chosen burner before purchasing.

🏡 Designed for Contemporary Living

With its built in format, the Foco One 800 helps create a seamless finish without taking up the space required by a freestanding fireplace. It works particularly well in modern living rooms, feature walls and open plan interiors where a clean, uncluttered appearance is important.

The fireplace has a recommended minimum room volume of 70 m³. It provides supplementary warmth alongside an attractive flame display, making it a stylish addition to your home throughout the cooler months.

Safety

🛡️ Safety and Installation

The included tempered glass panel helps protect the flame from draughts, but it does not replace the safety precautions required for a bioethanol fireplace.

Installation should follow the manufacturer's instructions for the selected burner and the surrounding wall construction. When fitting the fireplace into a combustible wall, suitable heat insulation must be installed between the fireplace and the wall. Fire resistant boards, such as Skamotec Fire Boards or an appropriate equivalent, may be suitable when specified for the installation.

Although the frame is designed for straightforward assembly, the complete installation must meet the manufacturer's clearance, ventilation and wall construction requirements.

Important safety information:

• Use the fireplace only in a suitable, well ventilated indoor space that meets the manufacturer's minimum room size requirements.

• Never refill a burner while it is lit or hot. Allow it to cool completely before adding fuel.

• Use only the recommended bioethanol fuel and follow the burner manufacturer's operating instructions.

• Keep combustible materials, children and pets at a safe distance from the flames.

• Never leave a burning fireplace unattended.

• Do not assume that the absence of a chimney means that ventilation is unnecessary.

Specifications

📐 Dimensions and Technical Specifications

Product: Foco One 800 built in bioethanol fireplace

Brand: Foco Fires

SKU: BIO 30 128 manual

Fireplace type: Built in bioethanol fireplace

Viewing style: Single sided, front facing

Installation type: In wall installation

Fuel type: Bioethanol

Frame material: Steel

Finish: Black powder coated

Steel thickness: 4 mm

Height: 50 cm

Width: 80 cm

Depth: 40 cm

Weight: 25 kg

Packaged depth: 85.5 cm

Packaged weight: 27 kg

Maximum heat output: Depends on burner selected. The supplied manual burner specifications list approximately 1.6 to 3.3 kW, while some automatic options provide up to 4.2 kW.

Manual burner flame length: 45 cm

Manual burner fuel capacity: 3.5 litres

Manual burner fuel consumption: Approximately 0.46 litres per hour

Manual burner burn time: Up to 7.5 hours

Adjustable flame: Yes, depending on burner

Glass panel: Included

Glass height: 10 cm

Flue or chimney required: No

Minimum recommended room volume: 70 m³

Electrical requirements: None for the manual burner. Automatic burners require electricity, with the supply requirements depending on the selected model.

Controls: Manual, remote control or app control, depending on the burner selected

Warranty: 2 years

Please note that the stated heat output, fuel consumption and burn time depend on the burner fitted. Confirm the final specifications for your selected configuration before ordering.

Included

📦 What’s Included?

Foco One 800 fireplace frame supplied in five parts

• Manual bioethanol burner supplied as standard, based on the listed SKU and product specifications

• One tempered glass panel measuring 10 cm high

• Two glass holders

• Screws and nuts for assembly

Please note: This listing is for the manual burner configuration only. Automatic burners are not included and may be available as alternative configurations, subject to availability and compatibility. The manual burner is operated manually and does not require an electrical connection. Optional accessories, including an outer frame for a neater installation finish, are available separately.

Warranty

Warranty and Support

The Foco One 800 comes with a 2 year warranty for added peace of mind. Select the burner that best suits your home and desired controls, and ensure that the installation follows the manufacturer's safety requirements. With its contemporary black frame, front facing flames and flexible burner options, this built in bioethanol fireplace offers an elegant way to bring warmth and atmosphere into your living space.

FAQs

❓ Frequently Asked Questions

Does the Foco One 800 need a chimney?

No. The Foco One 800 is a bioethanol fireplace and does not require a conventional chimney or flue. The room must still meet the ventilation and minimum room volume requirements specified by the manufacturer.

Can I control the flames with a remote or mobile app?

Yes, if you select a compatible automatic burner. The manual burner is operated manually, while selected automatic models offer remote control, app functionality and adjustable flame settings.

How long does the Foco One 800 burn?

With the manual burner, the stated burn time is up to 7.5 hours. Actual operating time depends on the flame setting, fuel level and conditions. Automatic burners have different fuel capacities and burn times.

Is the glass panel included?

Yes. One tempered glass panel and two glass holders are included. The glass helps protect the flames from draughts and can be removed if permitted by the manufacturer's instructions.

Can I install the fireplace in a timber or other combustible wall?

A combustible wall requires suitable heat insulation and compliance with the installation instructions for the selected burner. Consult the manufacturer or a qualified installer to confirm the correct materials, clearances and construction before installation.

Is the Foco One 800 suitable for small rooms?

The recommended minimum room volume is 70 m³. Measure your room and confirm that it meets this requirement before installation.

Does the fireplace provide heating?

Yes. It produces supplementary heat as well as a real flame display. The output varies according to the burner selected, so check the relevant burner specifications when choosing your configuration.
