Foco Room Divider 800 Medium Bioethanol Fireplace

Description

🔥 Foco Room Divider 800 Medium Built in Bioethanol Fireplace

Create a striking focal point in your home with the Foco Room Divider 800 Medium, a three sided built in bioethanol fireplace designed to bring warmth and contemporary style to open plan interiors. Its compact 80 cm width and 30 cm depth make it ideal for creating a visual connection between two spaces while allowing the flames to be enjoyed from the front and both sides.

Part of the Foco Fires range, this fireplace combines a minimalist black finish with a choice of manual or automatic burner configurations, depending on your preferred level of convenience. It requires no chimney or flue, making it a versatile option for modern homes where a traditional fireplace installation may not be practical.

Features

✨ Key Features

• Three sided flame view for an attractive room divider feature

• Compact design measuring 80 cm wide, 50 cm high and 30 cm deep

• Black powder coated steel frame with a 4 mm thickness

• Tempered glass panels included to help shield the flames from drafts

• Adjustable flame with the manual burner

• No chimney or flue required

• Suitable for indoor installation in a room with a minimum volume of 70 m³

• Optional automatic burner configurations available separately

🔥 Manual Bioethanol Burner

The manual burner offers straightforward operation without the need for an electrical connection. Adjust the flame to suit your space and enjoy up to 7.5 hours of burning time, depending on conditions and flame settings.

Manual burner specifications:

• Heat output: 1.6 to 3.3 kW

• Fuel capacity: 3.5 litres

• Flame length: 45 cm

• Burn time: Up to 7.5 hours

• Flame adjustment: Yes

• Electricity required: No

• Control: Manual

The manual configuration is a practical choice for those who prefer simple operation without electronic controls.

⚙️ Automatic Burner Options

Automatic burner configurations may be available separately for those who prefer additional control features. The Planika BEV 700 option listed by the supplier includes remote control and a control panel, two flame levels and requires an electrical connection.

Automatic burner specifications supplied:

• Heat output: 2.2 to 4.1 kW

• Fuel capacity: 2.1 litres

• Flame length: 50 cm

• Burn time: Up to 6 hours

• Control: Remote control and control panel

• Electricity required: Yes

Please check the selected product configuration before ordering. The automatic burner is a separate configuration and is not included with the manual burner version.

🖤 Materials and Design

The Foco Room Divider 800 Medium features a minimalist black frame designed to complement contemporary interiors. Its three sided construction allows the fire to be enjoyed from multiple angles, making it suitable for installations between living rooms, dining areas and other open plan spaces.

The fireplace is made from 4 mm thick steel with a black powder coated finish. Tempered glass panels are included to help reduce the effect of drafts on the flames. For additional shielding, a compatible full height glass panel can be purchased separately. Glass configuration should follow the manufacturer's installation instructions.

Specifications

📐 Technical Specifications

• Brand: Foco Fires

• Model: Foco Room Divider 800 Medium

• Fireplace type: Built in bioethanol fireplace

• Flame view: Three sided

• Height: 50 cm

• Width: 80 cm

• Depth: 30 cm

• Frame material: Steel

• Finish: Black powder coated

• Steel thickness: 4 mm

• Fuel type: Bioethanol

• Maximum heat output: 3.2 kW listed for the fireplace

• Fuel consumption: 0.46 litres per hour

• Listed burn time: Up to 7.5 hours

• Flame width: 45 cm

• Adjustable flame: Yes

• Minimum room volume: 70 m³

• Chimney or flue: Not required

• Power requirements: None for the manual burner

• Glass panels: Included

• Intended use: Indoor

• Warranty: 2 years

• Packaged weight: 21 kg

Included

📦 What's Included?

For the manual burner configuration, the package includes:

• Foco Room Divider 800 Medium fireplace frame

• Manual bioethanol burner

• Three tempered glass panels, each 10 cm high

• Six glass holders

Please note: the manual burner is included with this configuration. A remote control, app control and automatic burner are not included. Automatic burner configurations must be selected separately where available.

🛠️ Installation

The Foco Room Divider 800 Medium is designed to be integrated into a suitable wall structure. Its 30 cm depth should be considered when planning the installation and surrounding construction.

Although no chimney or flue is required, bioethanol fireplaces still require adequate room ventilation and compliance with the manufacturer's minimum room volume, clearances and installation instructions. Installation must follow the supplied manual and applicable local building and fire safety requirements.

Do not assume that fire resistant boards alone make a combustible wall suitable for installation. Use an approved installation system and consult a qualified installer where necessary. Never refill the burner while it is lit or hot.

🧰 Optional Accessories

The following compatible accessories may be available separately:

• Heat Deflector for Foco 800

• Full Glass on One Side, 800 mm

Check compatibility and installation requirements before purchasing accessories.

Warranty

🛡️ Warranty and Support

The Foco Room Divider 800 Medium comes with a 2 year warranty, according to the supplied product specifications. Please refer to the manufacturer's warranty terms and installation documentation for full conditions.

For help with sizing, burner configurations or installation planning, contact the Sal's Place team before ordering.

FAQs

❓ Frequently Asked Questions

Does the Foco Room Divider 800 Medium need a chimney?

No. It does not require a chimney or flue. However, adequate ventilation and the manufacturer's room volume and installation requirements must still be followed.

Can the flames be viewed from both rooms?

Yes. Its three sided design allows the flames to be viewed from the front and both sides, making it suitable as a feature between connected spaces.

Does the manual version include a remote control?

No. The manual burner is operated manually and does not include a remote control or app control. Automatic burner configurations are separate options.

Does the fireplace require electricity?

The manual burner does not require electricity. An automatic burner, such as the Planika BEV 700 configuration, requires a power connection.

How long does it burn on one fill?

The listed burn time for the manual burner is up to 7.5 hours. Actual burn time depends on the flame setting and operating conditions.

Can I install it in a combustible wall?

The installation must follow the manufacturer's instructions and applicable safety requirements. Do not rely on fire resistant boards alone to make a combustible wall safe. Seek advice from a qualified installer before proceeding.
