Foco Three 1500 Three Sided Built In Bioethanol Fireplace

Description

Foco Three 1500 Three Sided Built In Bioethanol Fireplace 🔥

Make a bold statement in your home with the Foco Three 1500 bioethanol fireplace. With its impressive 150 cm width and panoramic three sided flame view, this built in fireplace creates a striking centrepiece for contemporary living rooms, open plan interiors and modern media walls. Enjoy the flames from the front, left and right, bringing warmth and atmosphere to your space from multiple angles.

The Foco Three 1500 comes as standard with two manual bioethanol burners, giving you an extended flame display across the fireplace. If you prefer greater convenience, you can choose a compatible automatic burner option with electronic controls and additional features, depending on the model selected.

Features

✨ Sleek Design and Durable Materials

Made from 4 mm thick steel with a black powder coated finish, the Foco Three 1500 combines a clean, minimalist appearance with a sturdy construction. Its understated black frame allows the natural movement of the flames to stand out, complementing a wide range of modern interior styles.

Three tempered glass panels are included to help shield the flames from draughts and support a steadier flame display. The glass panels can be removed where permitted by the manufacturer's instructions and the chosen installation configuration. Six glass holders are supplied for assembly.

Measuring 150 cm wide, 50 cm high and 40 cm deep, this fireplace is particularly well suited to larger feature walls and media wall designs. If you intend to position a television above it, check the manufacturer's clearance and heat protection requirements before installation.

🔥 Choose Your Bioethanol Burner

The Foco Three 1500 offers a choice of manual and automatic burner configurations to suit different preferences.

Two Manual Bioethanol Burners

The standard configuration includes two Superior manual bioethanol burners, each with a 3.5 litre fuel capacity and a flame length of approximately 45 cm. Together, they create an expansive flame display across the fireplace.

The burners do not require electricity. Lighting, flame adjustment and extinguishing are carried out manually in accordance with the supplied instructions. The stated combined heat output ranges from 3.3 kW to 6.6 kW, with a listed burn time of up to 6 hours.

Automatic Bioethanol Burners

For additional convenience, compatible automatic options include the Planika Prime Fire 2.0 1190, Planika FLA4 1190 and Planika FLA4+ 1190.

These models use electronic controls and require an electrical connection. Depending on the selected burner, features can include remote control, mobile app operation and multiple flame levels. The Prime Fire 2.0 offers three flame levels, while the FLA4 and FLA4+ offer six.

The FLA4+ has a larger 21 litre fuel capacity and a stated burn time of up to 30 hours. The other automatic options have different capacities and operating times. Check the specifications for your chosen burner before ordering.

Smart Home integration may be available with compatible Planika models and requires an additional Smart Home module. Remote controls and other accessories depend on the selected configuration.

Safety

🏡 Built In Installation and Safety

The Foco Three 1500 is designed for indoor use and does not require a traditional flue or chimney. It is suitable for built in installations when the surrounding enclosure and clearances meet the manufacturer's requirements.

The recommended minimum room volume is 95 m³. Adequate ventilation, suitable wall construction and appropriate heat protection are essential. If installing the fireplace in a combustible wall, use approved non combustible construction materials and insulation in accordance with the installation guide. Seek advice from a qualified installer if you are unsure about the wall structure or required clearances.

Never leave a burning fireplace unattended. Do not refill a lit or hot burner. Allow the burner to cool completely before refuelling, use only compatible bioethanol fireplace fuel and follow all instructions for lighting, operation and extinguishing.

Specifications

📐 Technical Specifications

• Brand: Foco Fires

• Product name: Foco Three 1500

• Product type: Three sided built in bioethanol fireplace

• Flame view: Front, left and right

• Installation: Indoor, feature wall or media wall

• Fuel type: Bioethanol

• Standard burner configuration: Two Superior manual burners

• Optional automatic burners: Planika Prime Fire 2.0 1190, Planika FLA4 1190 or Planika FLA4+ 1190

• Manual burner flame length: Two flames of approximately 45 cm each

• Manual burner fuel capacity: Two burners with 3.5 litres each

• Manual configuration burn time: Up to 6 hours, as specified

• Manual configuration heat output: 3.3 kW to 6.6 kW

• Automatic burner heat output: Up to 9.4 kW, depending on model

• Frame material: Steel

• Finish: Black powder coated

• Steel thickness: 4 mm

• Height: 50 cm

• Width: 150 cm

• Depth: 40 cm

• Minimum room volume: 95 m³

• Flue or chimney required: No

• Electrical connection: Not required for manual burners; required for automatic burners

• Remote control: Depends on the selected burner configuration

• Mobile app control: Available with compatible automatic burners

• Smart Home integration: Depends on the selected model and may require an additional module

• Glass: Three tempered glass panels included

• Packaged depth: 54.5 cm

• Packaged weight: 60 kg

• Warranty: 2 years

Included

📦 What’s Included?

• Foco Three 1500 fireplace frame

• Two Superior MANUAL bioethanol burners in the standard configuration, unless an automatic burner option is selected

• Three tempered glass panels, each 10 cm high

• Six glass holders

• Screws and nuts for assembly

Important: The standard configuration includes MANUAL bioethanol burners. Lighting, flame adjustment and extinguishing must be carried out manually. Automatic burners, remote controls and Smart Home controls are not included with the standard manual configuration. These features depend on the automatic burner option selected and may require additional purchases. Bioethanol fuel is not included.

Warranty

🛡️ Warranty and Support

The Foco Three 1500 comes with a 2 year warranty for added peace of mind. Before installation, review the manufacturer's instructions for your chosen burner and enclosure. If you need help with clearances, wall construction, heat protection or electrical requirements, consult a qualified installer.

Choose the Foco Three 1500 for a wide panoramic flame display, timeless black styling and the flexibility to select manual or automatic burner technology.

FAQs

❓ Frequently Asked Questions

Can I see the flames from three sides?

Yes. The Foco Three 1500 is designed to display flames from the front, left and right, making it ideal for feature walls and media walls.

Does the Foco Three 1500 come with two burners?

Yes. The standard configuration includes two Superior manual bioethanol burners. Compatible automatic burner options are also available.

Does it need a chimney or flue?

No. The fireplace does not require a traditional chimney or flue. You must still follow the manufacturer's minimum room volume, ventilation and installation requirements.

Does the manual version need electricity?

No. The two manual burners do not require electricity. Automatic burner configurations require an electrical connection.

Can I control the automatic burner with my phone?

Compatible automatic models offer mobile app control. Smart Home integration depends on the selected model and requires an additional Planika Smart Home module where supported.

Can I install it beneath a television?

It may be possible, but you must follow the manufacturer's clearance and heat protection instructions. Check whether a heat deflector or other protection is needed to protect the television and surrounding equipment.

Is the glass included?

Yes. Three tempered glass panels and six glass holders are supplied. Follow the manufacturer's instructions for fitting or removing the glass.
